TX20 pH and ORP Controller From Sensorex

Sensorex - TX20 pH and ORP Controller

The TX20 automatic pH controller is a convenient and cost effective solution for monitoring and maintaining pH and ORP. Save space in your panel with the small footprint 1/8 DIN case. Use the two on/off relay outputs to program process control, including management of alarms and chemical dosage systems.

• Easy to install 1/8 DIN Case

• Two on/off controls (relay outputs)

• Clear LCD displays pH or ORP and temperature

• 100-240 VAC power supply

Note: Transmitter is only compatible with sensors that have spade lug connectors.

Specifications

• Measurement Range (pH): -2.00 to 16.00pH, 0.01 pH resolution, +/- 0.1% accuracy

• Measurement Range (ORP/mV): -1999mV to 1999mV, 1mV resolution, +/- 0.1% accuracy

• Temperature Range: -10 °C to 120 °C , 0.1 °C resolution, +/- 0.3 °C accuracy

• Control Type/Relay Output: 2 ON/OFF controls / 5A at 115VC AC or 2.5A at 220V AC, resistive load only

• Enclosure: 1/8 DIN (3.78" L x 3.54" W x 1.89? H)

• Ambient Operating Temperature: 0° C to 50° C

• Temperature Compensation: Auto/Manual (-10 °C to 120 °C)

• Power Requirement: 100-240 VAC, max 500 ohm load

• Weight: 290g

Specification Sheet for 1/8 DIN pH and ORP Transmitters
