 Features
High efficiency, two vane, enclosed impeller for high efficiency pumping. Eliminates possibility of jamming between impeller and volute. Original performance can be restored if wear occurs by replacing volute seat ring. UL, CSA and SSPMA listed. Oil-filled motor for maximum heat dissipation and continuous bearing lubrication. High torque, permanent split capacitor (PSC) single-phase motors; no starting switches or relays to wear out.
HIGH HEAD PERFORMANCE FOR DEMANDING APPLICATIONS. DURABLE MOTOR WILL DELIVER MANY YEARS OF RELIABLE SERVICE.
Specifications
|
Capacities To
|
165 GPM
|
624 LPM
|
|
Shut-Off Head
|
70 ft
|
21.3 m
|
|
Max. Spherical Solids
|
2 in.
|
50.8 mm
|
|
Liquids Handling
|
drain water & domestic sewage
|
|
Intermittent Liquid Temp.
|
up to 140 F
|
up to 60 C
|
|
Motor Electrical Data
|
1/2 to 2 hp, 208/230 volts, 1 ph 208/230/460/575 volts, 3ph oil-filled, permanent split
capacitor type, 1ph , 3450 rpm, 60 hz
|
|
Motor Insultation
|
Class B (130 C)
|
|
Acceptable pH Range
|
5-9
|
|
Discharge, NPT
|
2 in.
|
50.8 mm. |
|
Simplex Sump Dia.
|
2 in.
|
61 mm. |
|
Duplex Sump Dia.
|
36 in |
91.4 mm. |
|
