Multi-Stage Vertical Booster Pumps
From G&L Goulds Pumps

Features

• Standard NEMA motors permit a wide variety of options and fast field service.

• NPT threads, ANSI flanges, in-line or top/bottom connections easily fit your piping requirements. The top discharge version may be swung in four directions.

• AISI 304 or 316L stainless steel liquid end components handle more of your pumping needs.

• Seal housing design promotes liquid flow and eliminates entrapped air or heat which could cause premature failure.

• Impeller O-ring seal produces high pressure and efficiency per stage to keep energy costs down.


• Impeller spacing is automatic for quick installation and reduced wear.


• Simplified design for maximum reliability and faster repair.


• Optional horizontal mounting and victaulic connections are available.


Applications

• Wide range of high pressure applications with flow rates up to 300 GPM

• Circulation of liquids without suspended solids

• Pressure boosting and water supply

• Agricultural and commercial irrigation systems

• Commercial washing systems

• Boiler feed and condensate return

• Water treatment

• Reverse osmosis and filtration systems

• Circulation of coolants such as glycol

• Pure water (demineralized and deionized) applications

• Circulation of hot and cold water for HVAC installations
