 This instrument is designed to be extremely accurate, fast and simple to use in diverse water quality applications. Advanced features include automatic temperature compensation; highly stable microprocessor-based circuitry; user-intuitive design; and waterproof housing. A true one-handed instrument, the PT2 is easy to calibrate and easy to use. To take a measurement, you simply push a button then dip the pen in solution. Results display in seconds.
High Performance Features
-
Accuracy of ±0.01 pH
-
1, 2 and 3 Point Calibration
-
Proprietary Sensor Design
-
Automatic temperature compensation
-
Reliable Repeatable Results
-
Rugged, reliable, shock-resistant fully encapsulated electronics
-
Durable body constructed of aircraft aluminum
-
Simple one button function
-
High capacity N-type battery included
-
Waterproof
Applications
| Range: |
0.00-14.00 pH |
0 - 71° C / 32 - 160° F |
| Accuracy: |
± 0.01 pH (After Wet Calibration) |
± 0.1 ºC / ± 0.1 ºF |
| Repeatability: |
± 0.01 |
± 0.1 ºC / ± 0.1 ºF |
| Resolution: |
0.01 pH |
0.1 ºC / 0.1 ºF |
| Time to Reading Stabilization: 10-30 seconds |
| Power Consumption: Active Mode 37 mA, Sleep Mode 2 µA |
| Temperature Compensation: Automatic to 25ºC |
| Physical Dimensions: 17.15 cm L x 1.59 cm D or 6.75 in. L x .625 in. D |
| Weight: 54 g/1.9 oz. (without soaker cap and lanyard) |
| Case Material: Anodized Aircraft Aluminum with Protective Coating |
| Battery Type: N type, Alkaline, 1.5V |
| Calibration Solutions: pH 4, pH 7, pH 10 |
| Operating/Storage Temperature: 0 - 55ºC or 32 - 131ºF |
| Enclosure Ratings: IP67 and NEMA 6 |
|
EN61236-1: 2006 – Annex A: 2008: Electrostatic discharge to case of instrument may cause PT2 to spontaneously power on. If this happens, the PT2 will power itself off within seconds.
|
