Truflo® LS Series Plastic Flow Meter

Truflo® LS Series Plastic Flow Meter

PADDLE WHEEL FLOW TRANSMITTER

Industry’s Most Accurate Paddle Wheel Flow Transmitter

All Plastic Construction

UltraFlo 4000 is a Flow Meter calculating the volume Flow of Liquids. Based on ultrasonic technology the UltraFlo 4000 is able to measure both conductive and non conductive liquids, as well as very corrosive liquids such as strong acids and alkalis. UIltra Truflo® has no moving parts and is absolutely free of wear. The design of the pipe minimizes dead space over the whole geometry. All parts having contact to the liquid is corrosion resistant Polysufon. UltraFlo is characterised by its high measurement accuracy and repeatability.

Features

  • EXCELLENT CHEMICAL RESISTANCE, PP, PVDF, PFA, CERAMIC

  • SIZE RANGE ½” – 24?

  • MEASURING FLOW RANGE (0.33 to 26 Ft/s)

  • EASY TO INSTALL

  • EXCELLENT FOR LOW or HIGH TEMPERATURES -25 to 90°C (-4 to 194°F)

  • NEMA 4X (IP65) or NEMA 6 (IP68) RATINGS

  • EXTRA LONG LASTING PFA PADDLE (ZIRCONIUM CERAMIC SHAFT & BEARINGS)

  • EXCELLENT DOUBLE O-RING SEAL

  • HIGH PRESSURE RATING (UP TO 200 PSI)

Specifications

Supply Voltage DC 24V
Measuring Accuracy ±0.75% of Full Scale
Repeatability ±0.5% of Full Scale
Pipe size 0.5 to 4 inch (DN15 to DN100)(T0)
6 to 24 inch (DN150 to SN600)(T1)
Output Frequency 60.5Hz per m/s nominal,
18.45Hz per ft/s nominal
Sensor Body Material PVDF, PP
Rotor Material PFA (TEFLON®)
Shaft and Beasings Material Zircoma Ceramic (ZrO2)
O-rings Materials FKM (Viton)
Electrical Connection DIN Mini-Connector 43650-A (IP65)
Electrical cable (IP68)
Cable Type 3 conductor + Shield.26A WG.PVC
Reverse Voltage Protection Included As Standard
Viscosity Range 0.5 to 20 Centi Stoke (cst)
Maximum Particle Size <10% with Particle Size
(<0.5mm cross section or length)
Maximum Operating Pressure/Temperature PVDF body (200 psi @ -30 to 80°C, 36 psi @ 90°F)
PP Body 180Psi -20to27°C 25Psi@80°C
Storage Condition PP Body (-30to90°C)
PVDF Body (-30to100°C)
CE EMC Certification EN 55022:1998



Truflo® LS Series Data Sheet
