nanoCorr Analyzers

Specifications for nanoCorr^TM CMS Analyzers and Corrosion Monitoring System:

• Number of independent probes for simultaneous measurements : up to 12

• Number of electrodes on each probe: up to 100

• Number of pH or ORP electrodes: up to 3 (S-Models only)

• Number of channels to receive analog signals from other meters such as humidity, pressure or flow pressure transducers: up to 3 (S-Models only)

• Corrosion current accuracy: <10 pA depending on noise of environments

• Corrosion rate accuracy: <10 nm/year or ~4x10-4 mil/year for typical applications

• Number of channels for probe potentials or corrosion potentials: up to 12

• Temperature channel: 1

• RS-232 (with up to 50' cable) or RS-485 (with up to 4000' cable) connection between the corrosion analyzer and a computer.

• Dimensions (H x W x D): 120 mm x 350 mm x 260 mm.

• Typical weight: 12 lb (5.5 kg).

• Operating environment: 0 to 50oC.

• Power supply: 120 V ± 10% or 120V/220 V±10%; 45 to 65 Hz frequency.

• Maximum sampling rate: <30 seconds for a 50-electrode-probe.

* Specifications may be changed at manufacturers discretion without notice or at customer's request.

Model A-18   ---   Model S-18

Model A-18: Measures up to 18 electrodes of  one to two independent probes.  Has three standard military connectors for different combinations of probes, an additional one channel for temperature, and two channels for the corrosion potentials of  probes.

Model S-18: In addition to the features of A-18, Model S-18 also measures up to three pH or three ORP probes, or three other transducers for parameters such as conductivity, humidity, flow, and pressure.

Model S-36: In addition to the features of A-36, Model S-36 also measures up to three pH or three ORP probes, or three other transducers for parameters such as conductivity, humidity, flow, and pressure.
