 Non-Metallic Air Operated Double Diaphragm Pump
Capacity: Adjustable 0 to 40 GPM
Max/Min Air Pressure:
LKT 70/20 PSI
Other Models 100/20 PSI
Dry Lift Capacity at MAX PSI:
Models w/ Teflon Balls 10 ft.
Other Models 15 ft.
 Models (Wetted Materials) Max Temp
LPB-1" (PP/BUNA N) 150°F
LPT-1" (PP/TEFLON) 150°F
LNT-1" (NYLON/TEFLON) 150°F
Applications:
drum and small tank transfer, pickling solutions, chemical feed, etc.
Features:
-
Absolutely lube-free and non stalling operation
-
Optional with Max-Pass™- valve system
-
Can safely run dry
-
Self-priming dry or wet
-
Centre block made of corrosion-free plastic
-
Few, easily accessible construction parts
-
Flow rate up to 156 l/min
Max-Pass™ compatible
Benefit:
-
No risk of pump failure due to to poor lubrication
-
No contaminating of the environment or of the product itself by oil vapour
-
Gentle pumping of liquids and pastes
-
Also for viscous liquids and large solid containing fluids (Max-Pass™)
-
Increased suction capability of the pump (Max-Pass™)
-
Greater freedom of installation ot the pump (Max-Pass™)
-
Possible air leakage arising at connections or in case of diaphragm rupture does not harm the air system
-
Easy maintenance without special tools
|
