Metallic AODD Pumps
 Capacity: Adjustable 0 to 14 GPM
Max/Min Air Pressure: All Models 100/20 PSI
Dry Lift Capacity at 100 PSI:
Models w/ Teflon Balls 10 ft.
Other Models 15 ft.
Models (Wetted Materials) Max Temp
LAB-1/2" (ALUMINUM/BUNA N) 180°F
 LAT-1/2" (ALUMINUM/TEFLON) 200°F
LSB-1/2" (STAINLESS/BUNA N) 180°F
LST-1/2" (STAINLESS/TEFLON) 200°F
Applications:
200 l-drum pumping, ink recirculation and feed, chemicals, solvents, acids, soap dispensing, etc.
Features:
-
Absolutely lube-free and non stalling operation
-
Can safely run dry
-
Self-priming dry or wet
-
Centre block made of corrosion-free plastic
-
Few, easily accessible construction parts
-
Flow rate up to 65 l/min
-
Explosion-proof version in compliance with ATEX
-
Directive 94/9/EC, category 2
Types:
-
DMP 1/2" Aluminium for neutral and inflammable liquids
-
DMP 1/2" Stainless steel for neutral, aggressive and
-
highly inflammable liquids
Benefit:
-
No risk of pump failure due to to poor lubrication
-
No contaminating of the environment or of the product itself by oil vapour
-
Gentle pumping of liquids and pastes
-
Flow rate and pressure can be regulated continuously
-
No dynamic seals
-
Possible air leakage arising at connections or in case of diaphragm rupture does not harm the air system
-
Easy maintenance without special tools
|
