2" Non-Metallic Air Operated Double Diaphragm Pumps
From Lutz Pumps

Non-Metallic Air Operated Double Diaphragm Pumps

Capacity: Adjustable 0 to 150 GPM

Max/Min Air Pressure:
LKT 70/20 PSI
Other Models 100/20 PSI

Dry Lift Capacity at MAX PSI:
Models w/ Teflon Balls 10 ft.
Other Models 15 ft.

Models (Wetted Materials) Max Temp
LPB-2" (PP/BUNA N) 150°F
LPT-2" (PP/TEFLON) 150°F
LKT-2" (PVDF/TEFLON) 200°F

Applications:
Paint, latex, ceramic slip, slurries, polymers, tank car fill and empty, foods, etc.

Features:

• Absolutely lube-free and non stalling operation

• Can safely run dry

• Self-priming dry or wet

• Centre block made of corrosion-free plastic

• Few, easily accessible construction parts

• Flow rate up to 681 l/min

Benefit:

• No risk of pump failure due to to poor lubrication

• No contaminating of the environment or of the product itself by oil vapour

• Gentle pumping of liquids and pastes

• Flow rate and pressure can be regulated continuously

• No dynamic seals

• Possible air leakage arising at connections or in case of diaphragm rupture does not harm the air system

• Easy maintenance without special tools
