2450
|
LonWorks Technology-based Reverse Osmosis Monitor including the Real Time Clock
|
|
|
(-RTC) option. Sensors and water meters ordered separately.
|
|
CONTROLLER OPTIONS
(optional; select no more than two, two -35L may be purchased)
|
|
-35L
|
Two 4-20 mA outputs (two -35L cards may be used for up to 4 outputs).
|
|
-RS2L
|
Communications node with the LRWS program
|
|
SENSOR OPTIONS
|
|
1104593
|
pH High Purity sensor, 1/4 inch NPT flow cell
|
|
520-4-7I-10-STD
|
pH sensor 0-14 pH, 3/4 inch NPT
|
|
540K0.1-4-10I-10-TC 500
|
Conductivity Sensor 0-10 µS, 3/4 inch NPT
|
|
540K.1-4-10I-10-TC 500
|
Conductivity Sensor 0-100 µS, 3/4 inch NPT
|
|
543-L-4-8I-10-STD
|
Conductivity Sensor 0-1000 µS, 1 inch NPT
|
|
543-M-4-8I-10-STD
|
Conductivity Sensor 500-100,000 µS, 1 inch NPT
|
|
AUTOTROL TURBINE WATER METER OPTIONS
|
|
1TM-NPT
|
1 inch turbine water meter with brass pipe thread adapters
|
|
1TM-ESW
|
1 inch turbine water meter with PVC solvent weld adapters
|
|
2TM-NPT
|
2 inch turbine water meter with brass pipe thread adapters
|
|
2TM-ESW
|
2 inch turbine water meter with PVC solvent weld adapters
|
|
49C25
|
25 ft cable for turbine meters
|
|
49C50
|
50 ft cable for turbine meters
|
|
SOFTWARE AND EXTERNAL MODEM OPTIONS
|
|
LRWS
|
Windows-based registered software for computer to communicate with 2000 Series Controllers.
|
|
MD4X
|
High-Baud modem in NEMA-4 enclosure ready to power
|
|
MD
|
High-Baud modem for use with 2000 Series Controllers
|
The Model 2450 uses LonWorks® Technology which is the latest in microprocessor capability that gives the user the highest level of application flexibility.
