F-300S Sensor Accessory - Blue-White Industries
|
Is your recirculation pump working? Is your recirculation system at the correct flow rate? Is your chemical pump injecting into a stopped system? Is your filter clogged? How Does it work? Optional Flow Switch / Sensor is designed to detect Flow / No Flow. A rare earth magnet is located within the red PVDF float of the new F-300 flowmeters. When the magnet passes through the Alarm Trigger Zone (Hysteresis) of the Sensor Accessory, the built-in contact closure switch sends a signal to external devices. Note: Two alarms can be placed onto one meter to obtain both ‘Flow Switch’ and ‘Flow Sensor’ capabilities. See diagrams below. Specifications
*For use with F-300 flowmeters which contain a RED float. Functions Flow Rate Sensor
Detects if water flow rate is at desired level. A built-in contact closure switch can remotely turn on/off a chemical pump and/or other external devices when flow rate is within desired range. Additionally, this can be used as an alarm signal if flow rate is not within flow range target, potentially indicating a clogged filter, malfunctioning equipment, closed valve, etc.
ie. Target water flow rate is 65 GPM, alarm is placed so that 65 GPM is positioned in middle of indicator window. Sensor will trigger alarm at flow from 60 to 70 GPM Flow Switch
Detects if water is flowing through the pipe. If float leaves “Alarm trigger zone,” a built-in contact closure switch can remotely turn on/off a chemical pump and/or other external devices.
|
F-300S Sensor Accessory
